Features

�EThe largest 5.7 inch responsive LCD touchscreen for a 320x240 infrared camera
�E180�X articulating lens for those tough shots
�EPremium image quality with leading spatial resolution for a 320x240 infrared camera¹
�EGet up to 4 times the resolution and pixels than standard mode with SuperResolution (up to 307,200 pixels)
�ELaserSharpR Auto Focus - utilizing precision laser technology, focus on your target with pinpoint accuracy and get the correct image and temperature measurements you need
�EBuilt-in laser distance meter - calculates the distance to your designated target up to 100 feet (30 meters) and displays the distance on the image
�EQuick and easy in-field analysis with IR-FusionR technology and advanced touchscreen functions:

�E	Continuous auto blend - easy identification of location and problem with visible and IR image blending
�E	Continuous level and span adjustment
�E	Combine multiple frames of data into one premium image with Image Sharpening
�E	Filter mode for improved thermal sensitivity

�EPost capture image editing includes:

�E	Emissivity
�E	Background temperature
�E	Transmissivity
�E	Palettes
�E	Color alarms
�E	IR-Fusion
�E	Enable/disable markers

�ERemote viewing and control options
�ETemperature measurements up to 1200�XC
�ELight and ergonomic design with neck and hand strap for all day use
�EOptional field installable wide angle and telephoto lenses

¹Compared to industrial handheld infrared cameras with 320x240 detector resolution as of October 14, 2014.

Specifications

Detailed Specifications
IFOV with standard lens (spatial resolution)	1.31 mRad
Detector resolution	320 x 240 (76,800 pixels)
Field of view	24 �XH x 17 �XV
Minimum focus distance	15 cm (approx. 6 in)
IFOV with optional telephoto lens	0.65 mRad
Field of View	12 �XH x 9 �XV
Minimum focus distance	45 cm (approx. 18 in)
IFOV with optional wide-angle lens	2.62 mRad
Field of view	46 �XH x 34 �XV
Minimum focus distance	15 cm (approx. 6 in)
SuperResolution*	On camera and in software
Image sharpening	Yes
LaserSharp® Auto Focus	Yes, for consistently in-focus images. Every. Single. Time.
Laser distance meter	Yes, calculates distance to the target for precisely focused images and displays distance on screen
Advanced manual focus	Yes
Streaming video (remote display)	Via USB
Touchscreen display (capacitive)	14.4 cm (5.7 in) diagonal landscape color VGA (640 x 480) LCD with backlight
Wireless	CNX Wireless (where available)
IR-FusionR technology	Yes
AutoBlend™ technology	Yes
Picture-In-Picture (PIP)	Yes
Continuous AutoBlend™	Set AutoBlend™ level across continuum
Rugged, ergonomic design for one-handed use	Rotatable (articulating lens) >180 degrees
Thermal sensitivity (NETD)	≤ 0.045�XC at 30�XC target temp (45 mK)
Filter mode (NETD improvement)	≤ 0.03 �XC at 30 �XC target temp (30 mK)
Level and span	Smooth auto and manual scaling
Touchscreen adjustable level / span	Yes. Span and level can be easy and quickly set by simply touching the screen.
Fast auto toggle between manual and auto modes	Yes
Fast auto-rescale in manual mode	Yes
Minimum span (in manual mode)	2.0 �XC (3.6 �XF)
Minimum span (in auto mode)	3.0 �XC (5.4 �XF)
Built-in digital camera (visible light)	5 megapixel industrial performance
Frame rate	60 Hz or 9 Hz versions
Laser pointer	Yes
LED light (torch)	Yes
Digital zoom	2x, 4x, 8x
Data Storage and Image Capture
Extensive memory options	Removable micro SD memory card, on-board flash memory, save-to-USB capability, direct download via USB-to-PC connection
Image capture, review, save mechanism	One-handed image capture, review, and save capability
Post-capture image editing (on camera)	Yes. Conduct on camera analysis for in-field results.
Advanced text annotation	Yes. Including standard shortcuts as well as user programmable options.
File formats	Non-radiometric (.bmp) or (.jpeg) or fully radiometric (.is2); no analysis software required for non-radiometric (.bmp, .jpg and .avi) files
Memory review	Thumbnail view navigation and review selection
Software	SmartView® software, Fluke Connect™ (where available), and SmartView® Mobile App - full analysis and reporting software
Export file formats with SmartView® software	BMP, DIB, GIF, JPE, JFIF, JPEG, JPG, PNG, TIF, and TIFF
Voice annotation	60 seconds maximum recording time per image; reviewable playback on camera; Bluetooth headset provided
IR-PhotoNotes™	Yes
Text annotation	Yes
Video recording	Standard and radiometric
File formats video	Non-radiometric (MPEG - encoded .AVI) and fully radiometric (.IS3)
Remote control and operation (for special and advanced applications)	Yes
Auto capture (temperature and interval)	Yes
Battery
Batteries (field-replaceable, rechargeable)	Two lithium ion smart battery packs with five-segment LED display to show charge level
Battery life	Three hours continuous use per battery pack
Battery charge time	2.5 hours to full charge
Battery charging system	Two-bay battery charger or in-imager charging. Optional 12 V automotive charging adapter
AC operation	AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz)
Power saving	User selectable sleep and power off modes
Temperature Measurement
Temperature measurement range (not calibrated below -10 �XC)	'-20 �XC to +1200 �XC (-4 �XF to +2192 �XF)
Accuracy	�� 2 �XC or 2 % (at 25 �XC nominal, whichever is greater)
On-screen emissivity correction	Yes (both value and table)
On-screen reflected background temperature compensation	Yes
On-screen transmission correction	Yes
Color Palettes
Standard palettes	8: Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted
Ultra Contrast™ palettes	8: Ironbow Ultra, Blue-Red Ultra, High Contrast Ultra, Amber Ultra, Amber Inverted Ultra, Hot Metal Ultra, Grayscale Ultra, Grayscale Inverted Ultra
General Specifications
Color alarms (temperature alarms)	High-temperature and low-temperature
Infrared spectral band	7.5 �gm to 14 �gm (long wave)
Operating temperature	-10 �XC to +50 �XC (14 �XF to 122 �XF)
Storage temperature	-20 �XC to +50 �XC (-4 �XF to 122 �XF) without batteries
Relative humidity	10 % to 95 % non-condensing
Center-point temperature measurement	Yes
Spot temperature	Hot and cold spot markers
User-definable spot markers	3 user-definable spot markers
Center box	Expandable-contractible measurement box with MIN-MAX-AVG temp
Safety	IEC 61010-1: Overvoltage Category II, Pollution degree 2
Electromagnetic compatibility	IEC 61326-1: Basic EM Environment CISPR11, Group 1, Class A
Australian RCM	IEC/61326-1
US FCC	CFR 47, Part 15 Subpart B
Vibration	0.03 g2/Hz (3.8 grms), 2.5g IEC 68-2-6
Shock	25 g, IEC 68-2-29
Drop	Engineered to withstand 1 meter (3.4 feet) drop with standard lens
Size (H x W x L)	27.3 cm x 15.9 cm x 9.7 cm (10.8 in x 6.3 in x 3.8 in)
Weight (battery included)	1.5 kg (3.3 lb)
Enclosure rating	IP54 (protected against dust, limited ingress; protection against water spray from all directions)
Warranty	Two-years (standard), extended warranties are available
Recommended calibration cycle	Two-years (assumes normal operation and normal aging)
Supported languages	Czech, Dutch, English, Finnish, French, German, Hugarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese and Turkish.
* Coming soon via firmware upgrade

Models & Accessories

Model Name Description     FLK-TiX560-60Hz Includes: Thermal imager with standard infrared lens Ac power supply and battery pack charger (including universal ac adapters) Two, rugged lithium ion smart battery packs USB cable HDMI video cable Bluetooth headset (where available) Rugged, hard carrying case Adjustable neck and hand strap Flash drive with SmartViewR Software and user manuals Warranty registration card and calibration certificate
Thermal Imaging Accessories
	Telephoto Infrared Lens (2X magnification) For use with Ti400, Ti300 and Ti200 Infrared Cameras. Optional, field swappable, 2X magnification telephoto thermal lens allows the user to see and measure the temperature of objects at greater distances, or smaller objects at normal distances. For use with the Ti400, Ti300 and Ti200 Infrared Cameras. Field-of-View (FOV) is 12 �X x 9 �X
	Wide-angle Infrared Lens 2 For added versatility and special applications use with Ti400, Ti300 and Ti200 models. Optional, field swappable, wide angle thermal lens allows the user to have a wider field of view for working in tight spaces. For use with the Ti400, Ti300 and Ti200 Infrared Cameras. Field-of-View (FOV) is 46 �X x 34 �X
Batteries, Chargers and Adapters
	FLK-TI-SBC3B Charging base for Ti-SBP3 Rechargeable Lithium-Ion Battery Packs. Use with models Ti400, Ti300, Ti200, Ti125, Ti110, Ti105, Ti100, TiR125, TiR110, TiR105, Ti32, TIR32, Ti29, TiR29, Ti27 and TiR27.
	TI-CAR CHARGER For the ultimate flexibility in the field - recharge your infrared camera wherever and whenever you need to. For use with all models except FlexCam.

Resources

TiX560 Safety Sheet >>

TiX560 Datasheet >>

TiX Brochure (English Version ) >>

TiX Brochure (Traditional Chinese Version ) >>

TiX Brochure (Simplified Chinese Version ) >>

Applications

Your view of infrared technology is about to change 180�X. The answer is right before your eyes, even when your target isn't. Navigate, capture and process images faster
	Easily navigate over, under and around objects with the 180�X articulating 1ens and see the image before you capture it Capture images with the only 5.7 inch responsive touchscreen LCD with on-camera analytics for in-field image analysis1 Save time with post-capture image processing - edit emissivity, background temperature, transmissivity, palettes, color alarms, IR-Fusion and enable/disable markers all on cameras
In-Focus premium image quality with the touch of a button
	Premium in-field viewing experience with the largest 5.7 inch responsive touchscreen LCD in its class1 - 150% more viewing area3 Enhanced image quality and temperature measurement accuracy �V turn your 320x240 images into 640x480 images, that's 4x's the resolution and pixels with SuperResolution (on camera) LaserSharp® Auto Focus, exclusive to Fluke, uses a built-in laser distance meter that calculates and displays the distance to your designated target2 with pinpoint accuracy2 Get premium image output in high temp applications by combining multiple sequential frames of data into one with Image Sharpening Find subtle temperature differences easier - instantly improve thermal sensitivity from 45mK to 30mK with Filter mode Optional field installable wide angle and telephoto lenses
1Compared to industrial handheld infrared cameras with 320x240 detector resolution as of October 14, 2014 2Up to 30 meters (100 feet) 3Compared to a standard 3.5 inch screen in this class
